Test Criterion：
        D.O.P.                        99.999995%             0.1 ~ 0.2 μm
        P.S.L.      Testing      99.99995%      at      0.1 ~ 0.2 μm
        D.O.P.                        99.9995%                  0.1 ~ 0.2 μm



---

Qualified with：
        En 1822 Class U15~U17
        IES RP-CC-001.3 TYPE F

Specifications
Dimensions(mm) without Inlet Duct			Capacity	Initial P.D.	Final P.D.
Length (L)	Width (W)	Depth (D)
305	610	50/70/90	4.8/4.8/8.1 CMM	D 50mm:25.4mm H2O *Face Velocity:0.5m/sec D 70mm:17.0mm H2O *Face Velocity:0.5m/sec D 90mm:25.4mm H2O *Face Velocity:0.85m/sec	D 50mm: 50.8mm H2O D 70mm: 34.0mm H2O D 90mm: 50.8mm H2O *Recommend
610	610	50/70/90	10.1/10.1/17.2 CMM
760	610	50/70/90	12.7/12.7/21.6 CMM
915	610	50/70/90	15.4/15.4/26.2 CMM
1220	610	50/70/90	20.7/20.7/35.2 CMM
570	570	50/70/90	7.6/7.6/7.6 CMM	D 50mm:17.0mm H2O D 70mm:24.0mm H2O D 90mm:10.0mm H2O	D 50mm: 34.0mm H2O D 70mm: 26.0mm H2O D 90mm: 20.0mm H2O *According to FU Performance
1170	570	50/70/90	15.1/15.1/15.1 CMM

Test Criterion：
        D.O.P.                        99.999995%             0.1 ~ 0.2 μm
        P.S.L.      Testing      99.99995%      at      0.1 ~ 0.2 μm
        D.O.P.                        99.9995%                  0.1 ~ 0.2 μm

Qualified with：
        En 1822 Class U15~U17
        IES RP-CC-001.3 TYPE F
