Test Criterion：
        D.O.P.                        99.999%
        P.S.L.      Testing      99.99%      at      0.3 μm
        D.O.P.                        99.97%



---

Qualified with：
        En 1822 Class U12/U13/U14
        IES RP-CC-001.3 TYPE A/B/C/D

Specifications
Dimensions(mm) without Inlet Duct			Capacity	Initial P.D.	Final P.D.
Length (L)	Width (W)	Depth (D)
305	610	50/70/90	6.3/8.1/11.5 CMM	D 50mm:25.4mm H2O *Face Velocity:0.65m/sec D 70mm:25.4mm H2O *Face Velocity:0.85m/sec D 90mm:25.4mm H2O *Face Velocity:1.25m/sec	D 50mm: 50.8mm H2O D 70mm: 50.8mm H2O D 90mm: 50.8mm H2O *Recommend
610	610	50/70/90	13.3/17.2/24.2 CMM
760	610	50/70/90	16.0/21.6/30.5 CMM
915	610	50/70/90	20.1/26.2/37.0 CMM
1220	610	50/70/90	27.0/35.2/51.8 CMM
570	570	50/70/90	5.8/7.6/7.6 CMM	D 50mm:12.0mm H2O D 70mm:10.0mm H2O D 90mm:8.0mm H2O Face Velocity:0.35m/sec	D 50mm: 24.0mm H2O D 70mm: 20.0mm H2O D 90mm: 26.0mm H2O *According to FU Performance
1170	570	50/70/90	11.6/15.1/15.1 CMM

Test Criterion：
        D.O.P.                        99.999%
        P.S.L.      Testing      99.99%      at      0.3 μm
        D.O.P.                        99.97%

Qualified with：
        En 1822 Class U12/U13/U14
        IES RP-CC-001.3 TYPE A/B/C/D
